Face Grooving Int. Face Grooving
See all 4 in this Product Family

‎GFQR 12-2.00-0.20 IC528

Screw clamped, face grooving inserts.
CHAMGROOVE
Item # ISC6402691
Brand: Iscar
Mfr#: 6402691
Price: Log in For Price
Quantity Available
loading...
Cutting Width (CW) 0.079″ Functional Width (WF) 0.217″
Insert Length (INSL) 0.354″ Axial Groove Outside Diameter Maximum (DAXX) 0.71″
Corner Radius (RE) 0.0079″ Axial Groove Outside Diameter Minimum (DAXN) 0.49″
Cutting Depth Maximum (CDX) 0.118″ Max. Face Grooving Feed (ffg(max)) 0.002 ″/rev
Cutting Edge Material Carbide Min. Face Grooving Feed (ffg(min)) 0.0008 ″/rev
Applicable Material | Steel | Stainless Steel | Super-Alloys / Titanium | Measurement Type Inch
Grade IC528 Coating TiCN+TiN
Application | Face Grooving | Int. Face Grooving | Body Material Carbide
Tool Type Face Turn-Groove Inserts Unit I
‎GFQR 12-2.00-0.20 IC528

Product Features

Family Description Screw clamped, face grooving inserts. BrandName Iscar
COO Israel
Warning-Proposition 65- For Californian Users only
WARNING:  This product contains a chemical known to the State of California to cause cancer or Birth defects.  For more information go to www.P65Warnings.ca.gov
FamilyName GFQR

Shipping Info

Weight per item
0.0119
Name
Face Groove/Turn Indexable Inserts
FamilyName
GFQR
BrandName
Iscar
